Nexen Rod Lock RLSS Series

More Views

Nexen Rod Lock RLSS Series

Call For Availability

Code: Rod Lock RLSS
Brand: Nexen

Industrial Clutch Parts Ltd. offer a full range of Nexen Rod Locks to assist the holding functions in precision linear drive systems. Our large stock of Nexen Rod Locks ensures prompt delivery and reduced lead times for our customers.

Nexen RLSS Series Rod Locks are spring engaged, high precision clamping elements. RLSS Rod Locks guarantee accurate positioning and provide precision holding while other operations are performed.

RLSS Rod Lock Features:

  • Precision operations maintain accurate positioning
  • Large clamping force ensures consistent performance
  • Sealed to withstand harsh environments

PDF Download Download
92 100 40
Description

Details

Nexen Rod Lock RLSS Series

Industrial Clutch Parts Ltd. offers a full range of Nexen Rod Locks designed to precisely lock and hold guide rods in position. ICP holds stock of both stand-alone and cylinder mounted rod locks (Cylinder mount versions can be stacked onto stand-alone version).

Nexen Rod Locks are available in natural brushed aluminum or with a black anodized coating. Comes standard with status feedback sensors for long live operations. The cam operated manual release feature mechanically disengages the rod lock with the simple turn of a hex screw using a standard wrench. Our offering includes clamping elements that fit onto ISO and NFPA pneumatic cylinders or on guide rods.

Nexen spring-engaged rod locks operate even in power-off situations to promote safety for operators and machinery. Multiple springs ensure reliable performance and redundancy. The fast response time of these spring engaged products also increases positioning accuracy.

Nexen's Rod Locks also feature locking mode sensing capability that allows engagement/disengagement feedback with the use of an optional inductive sensor. Every RLSS Rod Lock is sealed to protect internal components and operate in harsh wash-down environments.

RLSS Rod Lock Characteristics:

  • Max. Clamping Force: 12,500 N
  • Release Pressure: 4 bar
  • IP67 rated (anodized models exceed NEMA 4X rating)
Additional Information

Additional Information

Product Type Rod Lock
Brand Nexen
PDF Catalogue PDF Download Download
Industry Applications Machine Tools, Hydraulic Pressures, Scissor-lift Tables, Positioning Equipment, Amusement Ride Equipment, Print & Paper Handling Equipment, Theatre Platforms, Injection Moulding, Automation Systems...
Actuation Method Pneumatic
Bore Size 32 - 125 mm
Braking Force 800 - 8560 N
Brake Type Spring applied
Minimum Release Pressure 4 bar
Pressure 60 psi
Outside Diameter 12 - 32 mm
