Nexen Air Engaged Diaphragm Brake Type 8K & 12K

Brand: Nexen
Code: Nexen Air Engaged Diaphragm Brake Type 8K & 12K

Nexen Air Engaged Diaphragm Brake Type 8K & 12K

Short Stroke Actuator With Diaphragm.

Standard Drum Brake Models:

  • 8K

  • 12K





Out of stock

For further information, please contact us at:

95 100 23

Nexen Air Engaged Diaphragm Brake Type 8K & 12K

Nexen's 8K & 12K drum brakes are ideal for high torque slow speed control Applications. Hinged design for use with removable brake drums.

Characteristics:

  • Static torque at 6 bar: 174Nm (8K, Loco facing) 290Nm (8K, Std); 280Nm (12K, Loco) 460Nm (12K, Std)

  • Drum diameters: 203.2mm(8") and 302.8mm(12")

  • Max. speed: 2700 RPM

  • Bores: 0-100mm

  • 8 and 12-inch Drum sizes available

  • Speeds up to: 8K - 2700rpm; 12K - 1800rpm

Features:

  • High cooling capacity.

  • High friction work capacity.

  • High heat sink capacity.

  • Self adjusting for friction wear.

  • Standard of low coefficient facings.

  • Air Actuated for accurate, economical operation.

  • Long-wearing friction linings.

  • Diaphragm powered for high responsiveness

Product Specific Information

Please enter any product specific information to enable our engineers to specify the correct product or product for you.

Product Brake
Brand Nexen
Industry Applications Dynamic braking. Cyclic stops. Tension control. Holding.
Actuation Method Pneumatic
Ambient Temperature 32 - 122 °F
Compares With Horton
Bore Size 0-100mm
Max. RPM 2700
