Yaw Brake HAB-3-90 fits Gamesa G5X Wind Turbines

Brand: ICP
Code: AB0008

Industrial Clutch Parts Ltd. manufactures an extensive range of wind turbine braking systems. Many ICP brakes interchange with major manufacturers in the wind market.

ICP HAB-3-90 is a hydraulic applied yaw brake, specifically designed for Gamesa G5X wind turbines. ICP sets the industry standard for low noise, safe and reliable braking. Used worldwide by the majority of wind power plant manufacturers.

  • Braking Force: 122,000 N
  • Brake Type: Hydraulic, Yaw, Caliper
  • Wind Turbine: Gamesa G5X
  • Interchangeability: Gamesa C432029
Out of stock

For further information, please contact us at:

95 100 37

ICP HAB-3-90 Hydraulic Yaw Brake fits Gamesa G5X Wind Turbine

Industrial Clutch Parts Ltd. has produced an extensive range of lightweight, noise-free braking systems suitable for the majority of wind power plant manufacturers. ICP yaw & rotor brakes have been designed for braking and gliding processes in wind turbines.

ICP HAB-3-90 is a hydraulic yaw brake, specially manufactured for Gamesa G5X wind turbines. HAB-3-90 is an independent caliper and incorporates three hydraulic pistons to stop and hold the rotating nacelle in position once the rotors have been turned to face into the wind.

Product Specific Information

Please enter any product specific information to enable our engineers to specify the correct product or product for you.

Gamesa C432029
Product Brake
Brand ICP
Compares With Gamesa
Industry Applications Wind Turbine
Actuation Type Active
Braking Force 122,000 N
Friction Coefficient 0.40
Friction Material Organic
Piston Area 6361 mm2
Total Piston Area 19,083 mm2
Pressure Connection Port 1/4" BSP
Pad Area 29,352 mm2
Max. Clamping Force 305,000 N
Max. Wear Of Pad (Organic) 10 mm
Max. Working Pressure 18 Mpa
Operating Pressure 16 Mpa
