ICP Hydraulic Yaw Brake HHB-5-110 fits Gamesa G8X Wind Turbine

More Views

ICP Hydraulic Yaw Brake HHB-5-110 fits Gamesa G8X Wind Turbine

Call For Availability

Drawing Number: AB0018 Brand: Industrial Clutch Parts

Industrial Clutch Parts Ltd. manufactures an extensive range of wind turbine braking systems. Many ICP brakes interchange with major manufacturers in the wind market.

ICP HHB-5-110 is a hydraulic applied yaw brake, specifically designed for Gamesa G8X wind turbines. ICP braking systems set the industry standard for low noise, safe and reliable braking. Used worldwide by the majority of wind power plant manufacturers.

HHB-5-110 Features:

  • Clamping Force47,515 N
  • Brake Type: Hydraulic, Yaw, Caliper
  • Wind Turbine: Gamesa G8X
  • Interchangeability: Gamesa GP000136

PDF Download Download
99 100 18
Description

Details

Hydraulic Yaw Brake Fits Gamesa G8X Wind Turbine

Industrial Clutch Parts Ltd. has produced an extensive range of lightweight, noise-free braking systems suitable for the majority wind power plant manufacturers. ICP yaw & rotor brakes have been designed for braking and gliding processes in wind turbines.

ICP HHB-5-110 is a hydraulic yaw brake, specially manufactured for Gamesa G8X wind turbines. HHB-5-110 incorporates five active pistons and two passive spring-applied pistons to stop and hold the rotating nacelle in position once the rotors have been turned to face into the wind.

The active braking functions are used for stopping and holding; manufactured with a minimum air gap for faster braking and shorter response times. The spring-applied brake pistons are used for parking and emergency stopping in case of power failure; functioned to start when the oil pressure to the brake disappears.

ICP holds stock of all Gamesa G8X yaw brake component parts, including pistons, hydraulic and dust seals, centering pins, and bushings. All available directly from stock to ensure prompt delivery and reduced downtime.

Additional Information

Additional Information

Product Type Brake
Brand Industrial Clutch Parts
PDF Catalogue PDF Download Download
Industry Applications Wind Energy
Actuation Method Hydraulic
Actuation Type Active & Passive
Brake Type Caliper
Compares With Antec, Gamesa
Friction Coefficient 0.40
Friction Material Type Organic
Lining Area 54,094 mm²
Max. Clamping Force 47,515 N
Max. Wear Of Pad (Organic) 10 mm
Max. Working Pressure 18 Mpa
Operating Pressure 16 Mpa
Pad Area 54,094 mm²
Piston Area 9503 mm²
Total Piston Area 6361 mm²
OEM Numbers

Compares To OEM Numbers

Gamesa GP000136
Request A Quote

Get A Quick Quote For ICP Hydraulic Yaw Brake HHB-5-110 fits Gamesa G8X Wind Turbine

* Required Fields

Application Examples
Assembly of G8X Yaw Brake

Assembly of G8X Yaw Brake

Assembled G8X Yaw Brake Ready For Delivery

Assembled G8X Yaw Brake Ready For Delivery
