ICP HAB-2-90 Hydraulic Yaw Brake

Brand: ICP
Code: AB0001

Industrial Clutch Parts Ltd. manufactures an extensive range of wind turbine braking systems. Many ICP brakes interchange with major manufacturers in the wind energy market.

ICP HAB-2-90 is a hydraulic yaw brake, specifically designed for Vestas WD34 wind turbines. ICP sets the industry standard for low noise, safe and reliable braking. Used worldwide by the majority of wind power plant manufacturers.

  • Braking Force: 63,616 N
  • Brake Type: Hydraulic, Yaw, Caliper
  • Wind Turbine: Vestas WD34
  • Interchangeability: Dellner Brakes
Out of stock

For further information, please contact us at:

82 100 21

ICP HAB-2-90 Hydraulic Yaw Brake fits Vestas WD34 Wind Turbines

Industrial Clutch Parts Ltd. has produced an extensive range of lightweight, noise-free braking systems suitable for the majority of wind power plant manufacturers. ICP yaw & rotor brakes have been designed for braking and gliding processes in wind turbines.

ICP HAB-2-90 is an active brake caliper, manufactured to extremely tight tolerances to avoid oil leakage and expensive machine modifications. Ideal for applications where space is limited. The compact and robust yaw brake is suitable for low-temperature applications.

ICP hydraulic caliper brakes feature organic, asbestos-free linings to withstand the toughest of environments for long service periods. The brake can be installed in a horizontal or vertical orientation.

Product Specific Information

Please enter any product specific information to enable our engineers to specify the correct product or product for you.

Product Brake
Brand ICP
Industry Applications Wind Energy
Actuation Method Hydraulic
Actuation Type Active
Brake Type Caliper
Compares With Antec, Svendborg
Pressure Connection Port 1/4" BSP
Friction Coefficient 0.40
Max. Braking Force 63,616 N
Max. Wear Of Pad (Organic) 7 mm
Max. Working Pressure 14 Mpa
Operating Pressure 12.5 Mpa
Brake Disc Thickness 20 - 40 mm
Pad Area 14,673 mm²
Piston Area 6361 mm²
Total Piston Area 6361 mm²
