ATB Precision Step System - FLA 51 & 60
Industrial Clutch Parts Ltd. supplies a complete range of products associated with the ATB Laurence Scott precision step system. Best suited for fast and accurate positioning requirements.
ATB Fast Linear Actuator (FLA) is specially created for fast linear motion or where high cycling frequencies are required. The FLA system is superior with respect to cycling frequency, precise positioning, greater operating reliability and low service costs.
- Stroke: 4 - 25 mm
- Reaction Time: 7 - 10 ms
ATB Laurence Scott FLA - Fast Linear Actuator 51 & 60
FLA models are driven by air and are activated pneumatically or by vacuum. Used in conjunction with the SRB control electronics the actuators are commonly used for applications such as sorting, cutting, and positioning.
FLA is available as a diaphragm (60) or a piston (51). Each model is available with different lengths of stroke suitable for a variety of applications. The FLA is specifically made for applications where very fast linear motion or high cycling frequencies are required.
| Danfoss | FLA |
|---|
| Product | Linear Actuator |
|---|---|
| Brand | ATB Laurence Scott |
| Industry Applications | Sorting, Cutting, Positioning. |
| Actuation Method | Pneumatic |
| Ambient Temperature | 0 - 40 °C |
| Accuracy | 0.5 ± ms |
| Max. Working Pressure | 1 bar |
| Weight Range | 1.6 - 1.7 kg |
