ICP HAB-1-110 Hydraulic Yaw Brake
Industrial Clutch Parts Ltd. manufactures an extensive range of wind turbine braking systems. Many ICP brakes interchange with major manufacturers in the wind energy market.
ICP HAB-1-10 is a hydraulic yaw brake, specifically designed for Acciona 1.5 MW wind turbines. ICP sets the industry standard for low noise, safe and reliable braking. Used worldwide by the majority of wind power plant manufacturers.
- Braking Force: 60,800 N
- Brake Type: Hydraulic, Yaw, Caliper
- Wind Turbine: Acciona 1.5 MW
- Interchangeability: Antec
ICP HAB-1-110 Hydraulic Yaw Brake fits Acciona 1.5 MW Wind Turbine
Industrial Clutch Parts Ltd. has produced an extensive range of lightweight, noise-free braking systems suitable for the majority wind power plant manufacturers. ICP yaw & rotor brakes have been designed for braking and gliding processes in wind turbines.
ICP HAB-1-110 is an active yaw brake, manufactured to extremely tight tolerances to avoid oil leakage and expensive machine modifications. Designed to control, stop and hold the rotating nacelle in position once the rotors have been turned to face into the wind.
|Industry Applications||Wind Energy|
|Compares With||Antec, Svendborg|
|Pressure Connection Port||1/4" BSP|
|Max. Braking Force||60,800 N|
|Max. Wear Of Pad (Organic)||7 mm|
|Max. Working Pressure||18 Mpa|
|Operating Pressure||16 Mpa|
|Brake Disc Thickness||20 - 50 mm|
|Piston Area||9512 mm²|
|Total Piston Area||9512 mm²|
